| Model | RE-201D | RE-301 | RE-501 | RE-1002 | RE-2002 | RE-5003 | |||||
| Rotary Bottle | 1L 24# | 3 L | 5L | 10 L | 20L | 50L | |||||
| Collecting Bottle | 1L 35# | 2 L 35# | 3L 35# | 5L | 10L | 20L | |||||
| Condenser | Vertical φ85 | Vertical | Vertical | Vertical three | Vertical three | Vertical three | |||||
| *460mm | φ100*510mm | φ100*590mm | backflow φ120*640mm | backflow φ130*680mm | backflow φ160*840mm | ||||||
| Charging Valve | 19# (standard size) | 34# (standard size) | 40# (standard size) | ||||||||
| Rotary Speed | 0-120rpm | 0-110 rpm | |||||||||
| Vacuum | 0.098 Mpa | ||||||||||
| Temp. Range | RT~400°C | ||||||||||
| Temp.Accuracy | ±1°C | ||||||||||
| Stroke Height | 120mm | 180mm | |||||||||
| Rotary Power | 30W | 40W | 120W | ||||||||
| Heating Power | 1.5KW | 2KW | 3KW | 5KW | |||||||
| Shelf Material | Stainless steel | Coating anticorrosive | |||||||||
| Chamber Material | SS 250 | SS 255 | SS 280 | SS 550 | SS 450 | SS 350 | |||||
| *140mm | *170mm | *170mm | *320mm | *250mm | *220mm | ||||||
| Plate size | 280 | 350 | 534 | 474 | 550 | ||||||
| *330mm | *330mm | *504mm | *474mm | *320mm | |||||||
| Power Supply | AC220/110V±10%,50/60Hz | AC220V±10%,50Hz | AC380V/220V±10%,50Hz | ||||||||
| External Size(mm) | 700*440 | 660*330 | 700*335 | 970*480 | 1170*540 | 1520*620 | |||||
| *885 | *970 | *1009 | *1950 | *2200 | *2470 | ||||||
| Package Size(mm) | 590*460 | 1000*460 | 1040*620 | 1350*350 | 1370*700 | 1450*390 | |||||
| *460 | *450 | *410 | *400; | *680; | *440; | ||||||
| 1280*570 | 700*680 | 1150*840 | |||||||||
| *660 | *740 | *660; | |||||||||
| 790*730 | |||||||||||
| *790 | |||||||||||
| Gross Weight | 21 Kg | 38 Kg | 38 Kg | 100 Kg | 123 Kg | 170 Kg | |||||
| Standard | 1L | 3L | 5L | 10L | 20L | 50L | |||||
| Accessory | Rotary | Rotary | Rotary bottle*1, | rotary | rotary | rotary | |||||
| bottle*1, | bottle*1, | 3L | bottle*1, | bottle*1, | bottle*1, | ||||||
| 1L | 2L | Collecting | 5L | 10L | 20L | ||||||
| Collecting | Collecting | bottle*1, | collecting | collecting | collecting | ||||||
| bottle*1 | bottle*1 | bottle *1 | bottle *1 | bottle *1 | |||||||
| Optional Accessory | Transparent bath cover, Explosion-proof transducer | Explosion-proof transducer, Explosion-proof motor | Explosion-proof transducer, Double collection bottle, Auto-lifting, | ||||||||
| EX40W | Explosion-proof motor EX120W | ||||||||||
| Vacuum pump, Recirculating chiller | |||||||||||
